PS800x4 - Mini 4 Channel Amplifier
PS800x4 - Mini 4 Channel Amplifier
Couldn't load pickup availability
Free Shipping on orders over $50.
The DC-PS800x4 is a compact series full bridge amplifier capable of making 800 watts. It’s High power 4 Channel amplifier. It has 4awg inputs and can be ran 4 ohms per channel, 2 ohms per channel or bridged at 4ohms
The Crossover network is what makes this one really shine, A section for channels 1/2 and 3/4 including Gain, HPF, LPF, Full Range AND a x10 switch to be able to active run your highs.
Output Power (RMS)
4 ohm 130Wx4 @ 14.4 Volts
2 ohm 220Wx4 @ 14.4 Volts
4ohm rms bridged power : 450W x 2
Key Features
4 ohm bridged stable
2 ohm stereo stable
Variable low pass filter
Variable High pass filter
Full Range Output
9-16.0 Volts Capable
x10 Crossover Switches
Tiffany Style RCA Jacks
Power / Protect LED
AMP SPECS:
| DC Amp Model: | PS-800x4 |
|---|---|
| Input Sensitivity | 8V~0.4V |
| Frequency Response | 10Hz~30KHz |
| 12dB / Octave Crossover | YES |
| High / Low Pass / Full Range w/ x10 Switch | YES 50-500Hz |
| Subsonic Filter | NO |
| Bass Boost @45hz | NO |
| Phase Shift | NO |
| Remote Control | NO |
| Clip Indicator | NO |
| Signal to Noise Ratio | dB90 |
| Damping Factor | 90< |
| THD @ 4ohms | 0.1% |
| Fuse Rating | External 80 amp |
| LED Status Lights | Power/Protect |
| Master/Slave | NO |
| Heatsink Length | 5.51"/140mm |
| Heatsink Width | 5.23"/133mm |
| Heatsink Height | 2.3"/60.0mm |
-
