DC Audio Level 6 Subwoofer

Subwoofer Description

The Lv6m6 Elite is DC Audio’s 4” Coil Beast. It has evolved into what most big builds are after, a sub that can take lots of power and Crush Out the Lows!!

With a world that has access to amplifiers of today's size we knew we needed a subwoofer that could keep up. A Large flat wound 4” Coil and 10” Spaced Spiders with Plenty of Xmax clearance is what we have to offer in the Level 6!!

The new Lv6m6 Elite will find itself at home in the SPL lanes or slappin down your hometowns cruise strip.

To really step it up with this driver take a look at the Carbon Fiber cone and dustcap options available for it.

2025’s New features include a wire cut top plate, Full inner Aluminum sleeve shortning ring, Longer pole and more rearward coil clearance. We have also tooled a new Motor boot with a embossed DC Audio and LV6 Logo on it.

Key Features

• Extremely strong kraft pulp fiber reinforced cone

• Wide Long Throw foam surround

• Dome propylene dust cover with White DC logo

• 10” OD Spaced Spiders

• Extra heavy duty sewn tinsel lead wire

• Cast DC Series aluminum black frame / no invert mount

• FEA analyzed and optimized motor assembly – Fully CNC machined

• Rubber mounting gasket

• 8 AWG OFC Direct leads

• 4.0” 8 Layer Hi-temp Aluminum voice coil wound on a Black Anodized Aluminum former

• Rubber magnet cover

• Aluminim shortening ring

• Extended Pole

                                             T/S Parameters

  M6 Level 6 Subwoofer	15"	18"
  Mounting Depth	12.75"	14.0"
  Mounting Hole Diameter	14.25"	16.9"
  Outside Driver Diameter	15.7"	18.5"
  VC Diameter	4"	4"
  Displacement	.24 ft³	.27 ft³
  Power Handling RMS	4500 watts	4500 watts
  Power Handling PEAK	8000 watts	8000 watts
  Ohm Options	d.7/d1/d2	d.7/d1/d2
  Sd	791 cm²	1159 cm²
  Vas	46.3 L	88.7 L
  Cms	0.057 Mm/n	0.049 Mm/n
  Mms	583.6 g	748.83 g
  Fs	27.59 Hz	26.37 Hz
  Bl	36.41 N/A	36.15 N/A
  Re	4.77 Ohm	5.39 Ohm
  Le	2.02 mH	4.64 mH
  Qms	5.726	6.871
  Qes	0.3643	0.5119
  Qts	0.3425	0.4764
  Xmax	34mm	34mm
  Ref SPL @1 watt	86.16 db	86.92 db
  Suggest Sealed Box	N/A ft³	N/A ft³
  Suggested Ported Box	3.5 ft³	6.0 ft³
