DC Audio NEO 3.5 Subwoofer

$1,559.99

$1,559.99 ~~$1,829.99~~

Save 14%

Size 12" 15" 18"

Ohm D.7 D1 D1.4 D2

Proven Performance

Quantity

Secure SSL Payments

Free Shipping on orders over $50.

Description

Subwoofer Description

The NEO 3.5 is a High Motor Force subwoofer built for SPL or Ground Pounding !! NEO Columns and a open motor design keep heat off the 3.5” Voice Coil to let you play harder and longer.

Custom Coil and Spider Configurations to get every tenth of a db out of it available.

Key Features

• Extremely rigid paper cone assembly

• Large Roll “LR” Multilayered polymer foam surround

• Polypropylene dust cover with DC logo

• (5) 3.5x10” OD spiders

• Dual extra heavy duty interweaved tinsel lead wire

• Cast aluminum DC Tooled black frame / no invert mount

• Large Neo Columns

• Rubber mounting gasket

• Direct Leads

• 3.5" 8 layer hi-temp aluminum voice coil

T/S Parameters

NEO 3.5 Subwoofer
12" (Pre-Break-in)
15"
18"


Mounting Depth
10.5"
11.75"
12.75"

Mounting Hole Diameter
11.15"
14.25"
16.9"

Outside Driver Diameter
12.5"
15.7"
18.5"

VC Diameter
3.5"
3.5"
3.5"

Displacement
.19 ft³
.23 ft³
.26 ft³

Power Handling RMS
3500
watts
3500
watts
3500
watts

Power Handling PEAK
7000
watts
7000
watts
7000
watts

Ohm Options
d.7/d1/d2
d.7/d1/d2
d.7/d1/d2

Sd
494 cm²
791 cm²
1159 cm²

Vas
9.87 L
0.00 L
0.00 L

Cms
31.86 Um/n
00.00 Mm/n
00.00 Mm/n

Mms
488.77g
000.00 g
000.00 g

Fs
40.32 Hz
0.00 Hz
0.00 Hz

Bl
30.91 N/A
00.00 N/A
00.00 N/A

Re
1.99 Ohm
0.00 Ohm
0.00 Ohm

Le
2.73 mH
0.00 mH
0.0 mH

Qms
8.92
0.00
0.00

Qes
0.25
0.00
0.00

Qts
0.25
0.00
0.00

Xmax
34mm
34mm
34mm

Ref SPL @1 watt
85.74 db
0.00 db
N/A db

Suggest Sealed Box
N/A ft³
N/A ft³
N/A ft³

Suggested Ported Box
1.5 ft³
3.25 ft³
5.5 ft³

NEO 3.5 Subwoofer	12" (Pre-Break-in)	15"	18"
Mounting Depth	10.5"	11.75"	12.75"
Mounting Hole Diameter	11.15"	14.25"	16.9"
Outside Driver Diameter	12.5"	15.7"	18.5"
VC Diameter	3.5"	3.5"	3.5"
Displacement	.19 ft³	.23 ft³	.26 ft³
Power Handling RMS	3500 watts	3500 watts	3500 watts
Power Handling PEAK	7000 watts	7000 watts	7000 watts
Ohm Options	d.7/d1/d2	d.7/d1/d2	d.7/d1/d2
Sd	494 cm²	791 cm²	1159 cm²
Vas	9.87 L	0.00 L	0.00 L
Cms	31.86 Um/n	00.00 Mm/n	00.00 Mm/n
Mms	488.77g	000.00 g	000.00 g
Fs	40.32 Hz	0.00 Hz	0.00 Hz
Bl	30.91 N/A	00.00 N/A	00.00 N/A
Re	1.99 Ohm	0.00 Ohm	0.00 Ohm
Le	2.73 mH	0.00 mH	0.0 mH
Qms	8.92	0.00	0.00
Qes	0.25	0.00	0.00
Qts	0.25	0.00	0.00
Xmax	34mm	34mm	34mm
Ref SPL @1 watt	85.74 db	0.00 db	N/A db
Suggest Sealed Box	N/A ft³	N/A ft³	N/A ft³
Suggested Ported Box	1.5 ft³	3.25 ft³	5.5 ft³
