DC Audio Level 2 Subwoofer

DC Audio Level 2 Subwoofer

Regular price $259.99
Sale price $259.99 Regular price $319.99
Save 18%
Size
Ohm
Proven Performance

Secure SSL Payments

  • Visa
  • Shop Pay
  • PayPal
  • Mastercard
  • Discover
  • Apple Pay
  • American Express
  • Maestro

Free Shipping on orders over $50.

Description

About the Product

Subwoofer Description

NEW for 2025!! The latest Level 2 Subwoofer

Level 2 has been redesigned to give you more than ever before. In our testing 33% more output vs the last version.

The New Level 2 has a double-stacked FEA optimized motor. A chrome top plate and T yoke, 22 mm of X-Max, progressive spiders, 2.75" voice coil, cast basket, push terminals and a rating suggestion of 750w RMS/1500w peak power handling.

This sub works great in sealed or ported enclosures and definitely gives you more bang for your buck! Made with high quality parts. Designed in the USA by American Audio Engineers.

Key Features

• Extremely rigid non-pressed paper cone assembly

• Stitched Multilayered polymer wide roll foam surround

• Polypropylene dust cover with DC logo

• 8" OD Progressive roll High Output spiders

• Heavy duty flat tinsel lead wire sewn to the spider

• Cast aluminum black frame / no invert mount

• FEA analyzed and optimized motor assembly - Fully CNC machined

• Rubber mounting gasket

• Chrome spring loaded push terminals

• 2.75” Hi-temp copper voice coil wound on black anodized voice coil former

• Rubber magnet cover with Lv2 logo

M4 Level 2 Subwoofers 10" 12"
Mounting Depth 6.0" 6.5"
Mounting Hole Diameter 9.35" 11.00"
Outside Driver Diameter 11" 12.5"
VC Diameter 2.75" 2.75"
Displacement .13 ft .15ft
Power Handling rms/peak 750/1500 750/1500
Ohm Options d2/d4 d2/d4
Sd 330 cm 502 cm
Vas 9.42 L 18.5 L
Cms 60.895 u M/N 51.797 u M/N
Mms 268.892g 283.609 g
Fs 39.33Hz 41.5Hz
Bl 22.89 N/A 22.72 N/A
Re 7.0 Ohm 7.0 Ohm
Kxm 240.487 mH 235.151 mH
Qms 3.868 3.937
Qes 0.887 1.003
Qts 0.722 0.799
Xmax 22mm 22mm
Ref SPL @1 watt 80.0 db 83.1 db
Suggest Sealed Box .5 ft .75 ft
Suggested Ported Box 1.0 ft 1.25 ft

Key Features

Technical Specifications
