Subwoofer Description
The NEO 3.0 is a subwoofer built for SPL!! If you're looking for a SPL Championship proven subwoofer, here you go.
Custom Coil and Spider Configurations to get every tenth of a db out of it available.
Key Features
• Extremely rigid paper cone assembly
• Multilayered polymer foam surround
• Polypropylene dust cover with DC logo
• 4 8” OD semi cup progressive roll spiders
• Dual extra heavy duty interweaved tinsel lead wire
• Cast aluminum black frame / no invert mount
• FEA analyzed and optimized motor assembly – Fully CNC machined
• Rubber mounting gasket
• Chrome spring loaded push terminals
• 3.0" 8 layer hi-temp aluminum voice coil
T/S Parameters
| NEO 3.0 Subwoofer | 15" | 18" |
|---|---|---|
| Mounting Depth | 9" | 11.00" |
| Mounting Hole Diameter | 14" | 16.75" |
| Outside Driver Diameter | 15.7" | 18.5" |
| VC Diameter | 3" | 3" |
| Displacement | .23 ft³ | .26 ft³ |
| Power Handling RMS | 2200 watts |
2200 watts |
| Power Handling PEAK | 4400 watts |
4400 watts |
| Ohm Options | d.7/d1/d2 | d.7/d1/d2 |
| Sd | 791 cm² | 1159 cm² |
| Vas | 33.00 L | 0.00 L |
| Cms | 37.06 uM/n | 0.00 Mm/n |
| Mms | 394.93 g | 000.0 g |
| Fs | 41.59 Hz | 00 Hz |
| Bl | 46.26 N/A | 00.00 N/A |
| Re | 7.98 Ohm | 0.0 Ohm |
| Le | 7.01 mH | 0.0 mH |
| Qms | 7.54 | 0.00 |
| Qes | 0.38 | 0.00 |
| Qts | 0.36 | 0.00 |
| Xmax | 26mm | 26mm |
| Ref SPL @1 watt | 89.65db | 0.00 db |
| Suggest Sealed Box | N/A ft³ | N/A ft³ |
| Suggested Ported Box | 3.0 ft³ | 5.5 ft³ |
