DOWN4SOUND SB 10" SUBWOOFER - DVC | 500W RMS

Elevate your car audio system with the DOWN4SOUND SB 10” Subwoofer, designed to bring precise, deep bass and exceptional clarity to your setup. 500W RMS power handling, this subwoofer delivers a perfect balance of performance and durability for your audio needs.

QUICK NOTES:

• RMS Handling: 500W RMS
• Coil Size: 2.5 Inch
• Cutout Diameter: 9.06 inches / 230 mm
• Outer Diameter: 10.28 inches / 261 mm
• Mounting Depth: 6.46 inches / 164 mm
• Motor Height: 3.54 inches / 90 mm
• Net Weight: 41.9 lbs / 19 kg
• Gross Weight: 45.2 lbs / 20.5 kg
• Highly optimized suspension for accurate sound reproduction
• Compact yet powerful for high-performance setups

Technical Specifications:

• Revc (DC Resistance): 2.03 Ohm
• Resonance Frequency (Fs): 30.88 Hz
• BL Product: 19.38 T·m
• Total Moving Mass (Mms): 171.79 g
• Suspension Compliance (Cms): 151.45 μm/N
• Effective Piston Area (Sd): 506.71 cm²
• Equivalent Volume (Vas): 24.35 L
• Sensitivity (SPL): 83.0 dB
• Qms (Mechanical Q): 3.474
• Qes (Electrical Q): 0.555
• Qts (Total Q): 0.479
• Outside Diameter: 10.28 in (261 mm)
• Displacement: 0.09 cu ft

Recommended Enclosures:

• Ported Enclosure Size: 1.0 cu ft (net)
• Port Area: 15 sq in
• Port Tuning: 35 Hz
• Sealed Enclosure: Not Recommended
